Rotar RG Hydraulic Grabs are very reliable, service-friendly and extremely strong. They are the perfect grab for industrial demolitions and intensive sorting and recycling activities.
The RG Series comes in open, half open, and closed teeth versions, meaning there is a right Rotar Sorting / Demolition Grab for truly any application.
We offer Rotar Grabs to either hire or buy UK wide. Our expert team will help you choose the right hydraulic grab for your requirements.
Enquire Now
With 9 models available you’re sure to find a demolition grab to suit your machine and your requirements:
| Type RG | 5-N | 9-N | 12-N | 15-N | 22-N | 30-N | 40-N | 50-N | 60-N |
|---|---|---|---|---|---|---|---|---|---|
| Machine class (t) | 2-5 | 5-9 | 10-15 | 14-18 | 15-22 | 20-30 | 25-40 | 35-50 | 45-60 |
| Weight (kg) | 210 | 425 | 870 | 1015 | 1305 | 1600 | 2000 | 2200 | 3950 |
| Volume (l) | 100 | 140 | 325 | 400 | 530 | 640 | 900 | 1100 | 1500 |
| Closing force (kN)* | 12 | 26 | 41 | 41 | 53 | 61 | 70 | 80 | 115 |
| Rotar Hole-pattern | 100 | 110-120 | 130-140 | 130-140 | 130-140 | 140-150 | 140-150 | 140-150 | 200 |
| Dimension A (mm) | 1137 | 1350 | 1750 | 1830 | 2000 | 2190 | 2425 | 2425 | 3050 |
| Dimension B (mm) | 500 | 650 | 800 | 900 | 1000 | 1100 | 1200 | 1400 | 1500 |
| Dimension C (mm) | 703 | 975 | 1380 | 1410 | 1525 | 1500 | 1578 | 1578 | 1850 |
| Max. operating pressure clamshell (bar) | 320 | 320 | 320 | 350 | 350 | 350 | 350 | 350 | 350 |
| Oil Volume clamshell (L/min) | 35 | 50 | 80 | 100 | 100 | 100 | 120 | 120 | 200 |
| Max. operating pressure hydromotor (bar) | 120 | 120 | 140 | 140 | 140 | 170 | 170 | 170 | 170 |
| Oil volume hydromotor (L/mi) | 20 | 20 | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
* Closing force by 320 Bar
