A Rotar Screening Drum for excavators and wheel loaders is the most effective way to sieve, sort, wash, mix, and clean a variety of materials. As the largest sieving surface available on the market, and with its laying-sieve option, the Rotar Screening Drum can sieve every kind of material in any desired size.
We offer Rotar Screening Drums to either hire or buy UK wide. Our expert team will help you choose the right screening drum for your requirements.
With 5 models for Excavators (HEX) and 7 models for Wheel Loaders (HPL) we’ll help you find the Screening Drum to suit your machine:
| Type HEX/Excavator | 350 M | 700 S | 850 S | 1000 S | 1400 S |
|---|---|---|---|---|---|
| Machine class (t) | 7-12 | 13-15 | 15-20 | 20-25 | 25-35 |
| Drum weight (kg)* | 425 | 900 | 1200 | 1700 | 2150 |
| Drum capacity (l) | 350 | 650 | 870 | 1050 | 1450 |
| Dimension A (mm) | 885 | 1170 | 1585 | 1130 | 1565 |
| Dimension B (mm) | 1290 | 1640 | 2055 | 1750 | 2185 |
| Dimension C (mm) | 7055 | 835 | 835 | 1075 | 1075 |
| Oil volume (lpm) | A 75 / B 75 | A 75 / B 75 | A 75 / B 75 | A 125 / B 125 | A 125 / B 125 |
| Operating pressure min./max. (bar) | 120 / 250 | 120 / 250 | 120 / 250 | 120 / 250 | 120 / 250 |
| Distance between ribs (mm) | 45 | 45 | 60 | 60 | 60 |
| Rotar Hole-pattern | 110 - 120 | 140 - 150 | 140 - 150 | 140 - 150 | 140 - 10 |
| Type HPL/Wheel Loader | 400 M | 600 S | 800 S | 1500 S | 2000 S | 2500 I | 3000 I |
|---|---|---|---|---|---|---|---|
| Drum weight (kg)* | |||||||
| Drum capacity (l) | 400 | 600 | 800 | 1560 | 2000 | 2500 | 3000 |
| Dimension A (mm) | 1500 | 1600 | 800 | 1560 | 2000 | 2500 | 3000 |
| Dimension B (mm) | 2035 | 2120 | 2385 | 2935 | 3025 | 3130 | 3430 |
| Dimension C (mm) | 610 | 705 | 755 | 1000 | 1120 | 1170 | 1170 |
| Oil volume (lpm) | A 50 / B 50 | A 75 / B 75 | A 75 / B 75 | A 125 / B 125 | A 125 / B 125 | A 160 / B 160 | A 160 / B 160 |
| Operating pressure min./max. (bar) | 120 / 250 | 120 / 250 | 120 / 250 | 120 / 250 | 120 / 250 | 120 / 250 | 120 / 250 |
| Distance between ribs (mm) | 45 | 45 | 45 | 45 | 45 | 60 | 60 |
| Rotar Hole-pattern | 410 | 420 | 430 | 450 | 460 | 470 | 470 |
* Operation pressure 20-60 higher with B-hydraulics
