Static Concrete Pulverisers - Worsley Plant Hydraulic Machinery

Static Pulverisers

Incredible cutting power combined with easy to replace wear parts make this Rotar Static Pulveriser the perfect concrete pulveriser for secondary demolitions. The RSP-series can easily crush the concrete and remove the reinforcement.

We offer Rotar Pulverisers to either hire or buy UK wide. Our expert team will help you choose the right pulveriser for your requirements.

Enquire Now

With 4 models available you’re sure to find a pulveriser to suit your machine and your requirements:

Type RSP	20 S	25 S	30 S	40 S
Machine class (t)	16 - 25	20 - 30	25 - 35	32 - 50
Weight (kg)**	1950	2350	3170	4100
Cycle open/close (s.)	2,2 - 1	2,3 - 1,4	3,4 - 1,9	4,3 - 2,9
Closing force at tip of jaw 1 (t)	62	70	80	115
Closing force at tip of jaw 2 (t)	93	105	127	155
Rotar Hole-pattern	140-150	140-150	140-150	140-150
Dimension A (mm)	2280	2400	2710	3150
Dimension B (mm)	620	620	620	620
Dimension C (mm)	400	440	480	550
Dimension D (mm)	310	310	400	470
Dimension E (mm)	860	915	960	1155
Dimension F (mm)	800	855	1005	1155
Dimension G (mm)	200	250	250	300
Dimension H (mm)	1640	1640	1700	1990
Max. operating pressure motor (bar)	350	350	350	350
Oil volume cylinder (L/min)	150 - 225	150 -250	150 -250	250 - 300
Connector size	SAE 1"	SAE 1"	SAE 1"	SAE 1 1/4"

Download Pdf

* Dimensions under construction

** Weight exclusive adapterplate with bracket

Features
Brochure
Video

Features

Replaceable teeth
Specially developed speed valve
Cross-mounted hydraulic cylinder

Brochure

Rotar RSP Brochure
