HMAG PRO 700
The HMAG PRO 700 is a compact high-performance hydraulic magnet designed for efficient material handling in recycling, demolition, waste processing, and industrial environments. Despite its smaller footprint, it delivers strong magnetic power and reliable lifting performance, making it ideal for excavators or material handlers where fast response and excellent scrap handling capability are required. The unit combines robust construction with dependable magnetic force for daily heavy use.
Key features
• Strong lifting capacity for its size
• Ideal for scrap, cast iron, and steel slab handling
• Efficient power consumption with reliable magnetic performance
• Fast activation and release for high productivity
• Durable coil design with optimised resistance for long service life
Technical Specifications
-
Lifting Capacity 5500kg
-
Magnet coil power: 2.7 kW
-
Operating voltage: 220 VDC ±5%
-
Magnet coil allowed resistance: 16.1 Ω ±5%
Nominal lifting capacity
• Tear-off with air gap Ø300: 5500 kg
• Slabs and blocks: 2700 kg
• Cast iron pigs: 105 kg
• Scrap grade 3A: 80 kg
• Scrap grade 24: 70 kg
• Scrap grade 40: 40 kgHydraulic power requirements –
-
Minimum flow: 21 l/min
- Max pressure : 350 bar
| Industry | Construction, Construction and Civils, Demolition, Forestry and Landscaping, Quarrying, Rail, Recycling and Waste Management, Scrap Metal Processing |
|---|---|
| Range | |
| Material |
