Demolition Combi Shears

Combining incredible cutting power and easily replaceable wear parts, the Rotar Demolition Combi Shear is the perfect demolition shear for primary demolition activities. The RDC series gnaws its way through any construction.

We offer Rotar Combi Shears to either hire or buy UK wide.  Our expert team will help you choose the right combi shear for your requirements.

Enquire Now

Enquire Now

  • This field is for validation purposes and should be left unchanged.

With 4 models available you’re sure to find a combi shear to suit your machine and your requirements:

Type RDC 20 S 25 S 32 S 42 S
Machine class (t) 15 - 25 24 - 35 30 - 45 45 - 70
Weight (kg)* 1950 2670 3050 4100
Cycle open/close (s.) 1,9 - 1,2 2,2 - 2,4 2,5 - 2,8 2,6 - 2,6 - 2,8
Closing force at tip of jaw 1 (t) 63 68 85 102
Closing force at tip of jaw 2 (t) 80 100 125 140
Rotar Hole-pattern 140-150 140-150 140-150 140-150
Dimension A (mm) 2100 2259 2508 2730
Dimension B (mm) 760 760 760 880
Dimension C (mmm) 280 320 320 340
Dimension D (mm) 90 100 100 100
Dimension E (mm) 650 775 880 1020
Dimension F (mm) 750 900 995 1230
Dimension G (mm) 400 400 500 600
Max. operating pressure cylinder (bar) 350 350 350 350
Max operating pressure motor (bar) 170 170 170 170
Oil volume cylinder (L/min) 150 - 250 150 - 250 250 - 300 250 - 300
Oil volume motor (L/min) 40 - 60 40 - 60 40 - 60 40 - 60
Download Pdf

*Weight exclusive adapterplate with bracket

  • Features
  • Brochure
  • Video
Features
  • Replaceable teeth and cutting knives
  • Strong rotating headpiece and an over-dimensioned, double-rowed slewing ring
  • Specially developed speed valve
Brochure
Rotar RDC Brochure
Rotar RDC Brochure
