Orange Peel Grab

Rapid cycle times combined with a large volume make the Rotar RPG Orange Peel Grab the perfect attachment for transferring scrap. The RPG will move a mountain!

Enquire Now

With 5 models available you’re sure to find an orange peel grab to suit your machine and your requirements:

Type RPG	4-600	4-800	6-600	6-800	6-1000
Machine class (t)	16 - 30	16- 30	30 - 50	30 - 50	30 - 50
Volume (l)	600	800	600	800	1000
Weight (kg)* open	1590	1625	1860	1895	2100
Weight (kg)* halfopen	1675	1725	1950	2030	2250
Weight (kg)* closed	1732	1800	2025	2155	2390
Max. lifting capacity grab (t)	8	8	10	10	10
Dimension A (mm)	2340	2435	2362	2466	2540
Dimension B (mm)	1900	1930	1917	1964	1989
Dimension C (mm)	1435	1604	1435	1612	1740
Dimension D (mm)	2490	2692	2490	2693	2840
Max. operating pressure (bar)	350	350	350	350	350
Oil volume clamshell (L/min)	115	115	120	120	120
Max. operating pressure hydrometer (bar)	200	200	200	200	200
Oil volume hydrometer (L/min)	50	50	50	50	50

Download Pdf

*Weight exclusive adapterplate with bracket

Features
Brochure
Video

Features

Strong rotating headpiece and over-dimensioned slewing ring. The hydraulic motor on the headpiece provides high torque, allowing the orange peel grab to be moved to every possible position.
The hydraulic cylinders of the RPG-series are fitted with end-cushioning., able to take the heavy punches and protect the cylinders.
The RPG-series’ wear-resistant shell design guarantees optimal penetration.

Brochure

Rotar RPG Brochure
