Fully Hydraulic Oilquick Quick Couplers
Available for sale & hire

OilQuick is an automatic quick coupler system for excavators, which allows hydraulic work tools to be connected and disconnected from the drivers cab. The operator can change between various work tools within a few seconds, such as a hydraulic hammer, steel or concrete shears, sorting grapple, hydraulic magnet, compactor, sorting bucket, tilt bucket or tiltrotator.

Enquire Now

Enquire Now

  • This field is for validation purposes and should be left unchanged.

With a range of sizes available we’ll help you find the Oilquick quick coupler to suit your machine and your attachments:

OQ 40/24 OQ 45-5 OQ 60-5 OQ 65 OQ 70 OQ 70/55 OQ 80 OQ 90 OQ 120
Excavator size 1-5t 5-10t 8-18t 14-22t 15-28t 18-28t 25-40t 40-70t 70-120t
Max. output torque kNm 16 70 150 240 320 450 700 900 1250
Bucket radius mm 500 600 800 1050 1250 1550 1850 1850 1850
Force at bucket edge kN 32 120 190 230 255 290 380 485 675
Width (mm) 240 290 340 440 450 550 590 750 870
Weight (approx kg) 30 85 135 170 210 230 320 630 1200
  • Features
  • Brochures
  • Video
Features

The right tool always ready for the job

  • Change between various work tools within a few seconds!
  • Increased versatility and efficiency No oil spills, saving both money and the environment. No messy hose couplings.
  • Saves the knees and back of the driver when unnecessary jumps in and out of the cab is avoided.
  • The OilQuick system will not only make your excavator but also your company more flexible, competitive and cost effective.
  • OilQuick is an advanced quick coupler system for excavators and can be supplied in various models for machines from 1 to 120 tons.
Brochures
Oilquick Quickcoupler Range
Oilquick Quickcoupler Range
